GPU
RadeonT RX 5500 Graphics
2nd Gen 7nm GPU
RDNA Architecture
Engine Clock
Boost Clock: Up to 1845 MHz
Game Clock: Up to 1737 MHz
Game Clock is the expected GPU clock when running typical gaming applications, set to typical TGP(Total Graphics Power). Actual individual game clock results may vary.
Stream Processors
1408
Memory Size/Bus
4GB/128 bit GDDR6
Memory Clock
14 Gbps Effective
Displays
Maximum 4 Displays
Resolution
HDMIT: 4096×2160@60Hz
DisplayPort1.4: 5120×2880@60Hz
Interface
PCI-Express 4.0
Output
1x HDMI
3x DisplayPort
BIOS Support
Dual UEFI
API
Vulkan®
OpenGL® 4.6
OpenCL 2.0
DirectX® 12
Shader Model 6.4
Game Index
Extreme 1080P
Sapphire Features
Power Design
Free Flow
TriXX Supported
TriXX Boost
Intelligent Fan Control
Precision Fan Control
Robust VRM Cooling
Robust Memory Cooling
Dual-X Cooling Technology
Tough Metal Backplate
PCB Layers
Two-Ball Bearing
Fan Quick Connect
Fuse Protection
Dual BIOS
AMD Features
RDNA Architecture
2nd Gen 7nm GPU
GDDR6 Memory
Power Efficiency
PCI Express 4.0 Support
Video Streaming up to 8K
Display Port 1.4 (HBR3) / DSC
RadeonT Software
RadeonT Boost
RadeonT Image Sharpening
RadeonT Anti-Lag
AMD FidelityFx
Async Compute
RadeonT Rays Audio + True Audio Next
RadeonT FreeSyncT 2 HDR
Cooling
Dual-X Cooling
Dual Fan
Two-Ball Bearing
Form Factor
2 slot, ATX
Dimension: 233 x 121.8 x 39.6(mm)
Power Consumption
135W
OS
Linux®, Windows® 10, Windows® 7 64bit operating system required
System Requirement
Recommended 500 Watt Power Supply (Minimum 450 Watt Power Supply).
1 x 8-pin Power Connector.
PCI Express® based PC is required with one X16 lane graphics slot available on the motherboard.
Minimum 4GB of system memory. 8GB recommended.
